4 Popup Screen
5-22 WindO/I-NV4 User’s Manual
■ Open with Fade In
When opening a Popup Screen, select this to gradually fade in the popup screen from nothing to the transparency
specified in Transparency.
■ Close while changing Base Screen
Select this to close the displayed popup screen when changing the Base Screen.
■ Focus Order
Sets the focus order for Numerical Input and Character Input. The focus order is the order the focus moves between
Numerical Input or Character Input when the user presses the ENT key. Text can be input in Numerical Input or
Character Input that has focus. The focus order number starts from 0.
■ Security Group
Select a security group to restrict displaying the screen.
This option can only be set when Use Security functions is selected. The Use Security functions check box is set
on General tab in the Security dialog box.
Click to display the Security Settings dialog box. If you create a security group on the Security Settings
dialog box, you can select that created group. For details, refer to Chapter 23 “2.2 Adding and Editing Security
Groups” on page 23-19.
Vertical: The focus moves vertically from top to bottom.
Horizontal: The focus moves horizontally from left to right.
Custom: Sets the desired order for moving the focus.
On the View tab, in the Screens group, click Focus Order, and then click the parts in the order to
move the focus.
The focus moves in the following order when Numerical Input and Character Input on the screen is not
aligned to the left or top.
1
4
3
2
1
4
3
2
1234
5
890
67
1234
5
890
67
Vertical
X-axis left to right
Y-axis up to down
Horizontal
None: Any user can open this screen.
Administrator, Operator,
Reader, (Created security group): Only selected users can open this screen.
For details about the security function, refer to Chapter 23 “User Accounts and the Security Function” on
page 23-1.
