8 Selector Switch
8-146 WindO/I-NV4 User’s Manual
2-Notch R-return: After the knob switches from Ch1 to Ch2, it returns to Ch1 when the R-button is released.
2-Notch L-return: After the knob switches from Ch2 to Ch1, it returns to Ch2 when the L-button is released.
3-Notch No-return: The knob does not return when the operator's finger is released.
3-Notch R-return: • If the knob is switched to Ch3, it returns to Ch2 when the button is released.
• If the knob is switched to Ch1, or from Ch1 to Ch2, it stays where it is even if the button is
released.
Release
Default state
Press
0
1
1
0
Write
Write
Ch1
Ch2
Action
Operation
and view
Data
written
Release
Default state
Press
0
1
1
0
Write Write
Ch1
Ch2
Action
Operation
and view
Data
written
Release
Default state
Press R-button Release Press L-button Release Press L-button
0
0
1
Ch1
Ch2
0
1
0
Ch3
1
0
0
Write
Action
Write
Operation
and view
Write
Data
written
Release Press R-button Release Press R-button Release Press L-button
Default state
0
0
1
1
0
0
0
1
0
0
1
0
Write Write Write
Write
Ch1
Ch2
Ch3
Action
Operation
and view
Data
written
