WindO/I-NV4 User’s Manual 10-39
2 Character Input
10
Data Displays
Trigger Device Address: Specifies the bit device or the bit number of the word device that will be used to trigger
flash.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-68.
Flash intervals are set in the Flashing Cycle on the System tab in the Project Settings
dialog box.
Text Color: Selects the color (color: 256 colors, monochrome: 16 shades) of text when flashing.
Click this button to display the Color Palette. Select a color from the Color Palette.
Plate Color: Selects the plate color (color: 256 colors, monochrome: 16 shades) when flashing.
Click this button to display the Color Palette. Select a color from the Color Palette.
This option can only be configured when Standard is selected for Image Type on the View
tab.
