2 Line Chart
11-44 WindO/I-NV4 User’s Manual
■ Cursor Position data
■ Cursor Style
Store numerical data: To store the numerical data at the position indicated by the cursor in internal devices, select
this check box and specify the destination word device.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-68.
The data is stored in continuous device addresses starting from the specified device address
in order from Ch1 in the amount of charts displayed. The number of used device addresses
varies based on the data size. If there is no data at the cursor position, 0 is stored in the
device address.
Example: When specifying LDR10 and storing the numerical data in Ch1 to Ch3
Data size configured in the Data Log: 16 bits
Data size configured in the Data Log: 32 bits
Store date and time data: To store the date and time data at the position indicated by the cursor in internal devices,
select this check box and specify the destination word device.
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-68.
The year, month, day, hour, minute, and second are stored in continuous devices in order as
BCD starting from the specified device address. If there is no data at the cursor position, 0 is
stored in the device address.
Example: When storing the date and time data for October 1, 2011 12:01:30
Destination Numerical data
LDR10
LDR11
LDR12
Ch1 numerical data
Ch2 numerical data
Ch3 numerical data
Destination Numerical data
LDR10 LDR11 Ch1 numerical data
LDR12 LDR13 Ch2 numerical data
LDR14 LDR15 Ch3 numerical data
Destination Date and time data
LDR10 2011 (Year)
LDR11 10 (Month)
LDR12 1 (Day)
LDR13 12 (Hour)
LDR14 1 (Minute)
LDR15 30 (Second)
Line Type: Selects the cursor line type from the following.
Solid, Dot, Dash, Long Dash, Long Dash Dot, Long Dash Dot Dot
Line Size: Selects the cursor line size from the following.
1 dot, 2 dots, 3 dots, 5 dots
Line Color: Selects the line color for the cursor (color: 256 colors, monochrome: 16 shades).
Click this button to display the Color Palette. Select a color from the Color Palette.
