Figure 8 Rear side of Hybrid Flipper
1.2.4 Laminator
SMART-70 Laminator is the high performance laminator which cards are can be laminated with
high quality without warming-up by using the patented technology of the IDP’s “Instant direct
heating mechanism”. One roll of the holographic or clear laminating film can laminate 500 cards.
SMART-70 Laminator has following features.
 LCD and 4 buttons on the control panel are for user conveniences and users can easily
check the status of Laminator and adjust configuration.
 Indicator LED on the front side of Laminator displays the status of Laminator by using
the color, so user can intuitionally check the status of Laminator.
 For improving the convenience of changing a laminating film, film cartridge is
designed as the drawer type and laminating film can easily be changed.
 By using film cartridge lock lever, film cartridge can easily be locked and laminate
head can be moved up and down for the convenience of maintenance.
 For the prevention of thefts, physical locking mechanism and Kensington lock are
designed and applied to Laminator.
① Kensington lock
Kensington lock is usable.
② Communication port
To communicate between SMART-70 modules,
please connect to an adjacent module.
③ Power port
Please connect the 24V DC power adaptor
provided with Flipper.
④ Power switch
Turn On/Off
⑤ USB host communication port
To communicate with SMART-70 Printer via USB
when encoder or/and scanner is installed.
