97
B. Output Hopper cleaning 2
Please pull up the card cartridge while
pushing the cartridge release button as
Figure.
Figure 149 Output Hopper cleaning 2
C. Output Hopper cleaning 3
Please push a cleaning card into the card
gate of Output Hopper as Figure and clean
rollers by pushing in and pulling out the
cleaning card slowly and repeatedly.
Figure 150 Output Hopper cleaning 3
5.5 TPH (Thermal Print Head) replacement
A. TPH replacement 1
Please turn the ribbon cartridge lock lever of
Printer to the clockwise 90 degrees as Figure.
Figure 151 TPH replacement 1
