F. Please turn ribbon / film cartridge lock lever to the counterclockwise 90 degrees, so the lever
is returned to the vertical.
Figure 26 Ribbon / film cartridge locking
2.1.6 DISPOSABLE CLEANING ROLLER INSTALLATION
A. Please detach disposable cleaning roller holder from Input Hopper as figure.
Figure 27 Detachment of disposable cleaning roller holder
