2.2 Advanced Hardware Installation
When more than one same module is installed on SMART-70 system or encoding option is installed
into Hybrid Flipper, additional configuration is needed.
2.2.1 Module ID of SMART-70
Each module of SMART-70 has a specific ID to communicate with each other because a system
of SMART-70 is combined by multiple modules. In that case, if a printer is combined in the
system, the printer is a main agent of the communication, and if a printer is not combined in
the system, a laminator is a main agent of the communication.
The main agent of communication should only be a Master. Thus, the first printer should be the
Master and other printers should be the Slave when more than two printers are combined in a
system, and the laminators combined in the system should also be the Salve. The default
setting of SMART-70 Printer is the Master and SMART-70 Laminator is the Slave.
SMART-70 consists of Input Hopper(I), Printer(P), Laminator(L), Hybrid Flipper(H) and Output
Hopper(O). One byte is used for the module ID, the high four bits are for the module type and
the low four bits are for the module number. The module ID is as below.
Module
Default ID
ID Range
Input Hopper(I)
0x10
0x10 ~ 0x1F
Printer(P)
0x40
0x40 ~ 0x4F
Laminator(L)
0x50
0x50 ~ 0x5F
Hybrid Flipper(H)
0x60
0x60 ~ 0x6F
Output Hopper(O)
0x70
0x70 ~ 0x7F
When more than one same modules are combined in a system of SMART-70, the module ID
should be adjusted for distinguishing each other of the same modules.
For example, in case of IPHPLHLO, the module ID should be adjusted as below because two
printers, two Hybrid Flippers and two laminators are combined in a system of SMART-70.
Order of Modules
Module Name
Module ID
1
Input Hopper(I)
0x10
2
Printer(P0)
0x40
3
Hybrid Flipper(H0)
0x60
4
Printer(P1)
0x41
5
Laminator(L0)
0x50
