Î
IO=2D8h;
IRQ=10
Infrared port I/O port address is 2D8h and the
interrupt address is IRQ10
Î
IO=2C0h;
IRQ=10, 11
Infrared port I/O port address is 2C0h and the
interrupt address is IRQ10, 11
Î
IO=2C8h;
IRQ=10, 11
Infrared port I/O port address is 2C8h and the
interrupt address is IRQ10, 11
Î
IO=2D0h;
IRQ=10, 11
Infrared port I/O port address is 2D0h and the
interrupt address is IRQ10, 11
Î
IO=2D8h;
IRQ=10, 11
Infrared port I/O port address is 2D8h and the
interrupt address is IRQ10, 11
Î
IO=2E0h;
IRQ=10, 11
Infrared port I/O port address is 2E0h and the
interrupt address is IRQ10, 11
Î Duplex Function [Full Duplex]
Use the Duplex Function option to select the IR data transmission mode.
Î
Full Duplex DEFAULT
The communication channels is used to send and
receive the data in both directions at the same time.
Î
Half Duplex
Transmission signals are sent in both directions but one
direction at a time so half duplex lines can alternatively
send and receive data.
