5.3.7 F81866 Super IO Configuration
Use the F81866 Super IO Configuration menu (BIOS Menu 9) to set or change the
configurations for the serial ports and parallel port.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
F81866 Super IO Configuration
F81866 Super IO Chip F81866
> Serial Port 1 Configuration
> Serial Port 2 Configuration
> Serial Port 3 Configuration
> Serial Port 4 Configuration
> Serial Port 5 Configuration
> IrDA Configuration
> Parallel Port Configuration
Set Parameters of Serial
Port 1 (COMA)
---------------------
ÆÅ : Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 9: F81866 Super IO Configuration
5.3.7.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 10) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings [Auto]
E
nable or Disable Serial
Port (COM)
---------------------
ÆÅ : Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 10: Serial Port n Configuration Menu
