WSB-H810 PICMG 1.0 CPU Card

Page 127

Figure 6-21: Audio Driver Installation Complete

Step 8: The system reboots.

6.7 USB 3.0 Driver Installation

WARNING:

Do not run this driver’s installer (Setup.exe) from a USB storage device

(ie. external USB hard drive or USB thumb drive). For proper

installation, please copy driver files to a local hard drive folder and run

from there.

To install the USB 3.0 driver, please follow the steps below.

Step 1: Access the driver list. (See Section

6.2)

Step 2: Click “5-USB3.0”.

Step 3: Locate the setup file and double click on it.

Step 4: A Welcome Screen appears (

Figure 6-22). Click Next to continue.
