WSB-H810 PICMG 1.0 CPU Card
Page 104
5.4.2 System Agent (SA) Configuration
Use the System Agent (SA) Configuration menu (BIOS Menu 22) to configure the
System Agent (SA) parameters.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
VT-d [Disabled]
> Graphics Configuration
> NB PCIe Configuration
> Memory Configuration
Check to enable VT-d
function on MCH.
---------------------
ÆÅ
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 22: System Agent (SA) Configuration
Î VT-d [Disabled]
Use the VT-d option to enable or disable VT-d support.
Î
Disabled DEFAULT
Disables VT-d support.
Î
Enabled
Enables VT-d support.
5.4.2.1 Graphics Configuration
Use the Graphics Configuration (BIOS Menu 23) menu to configure the video device
connected to the system.
