WSB-H810 PICMG 1.0 CPU Card
Page 94
Î CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control [Auto Mode]
Use the CPU_FAN1 Smart Fan Control/SYS_FAN1 Smart Fan Control option to
configure the CPU/System Smart Fan.
Î
Auto Mode DEFAULT
The fan adjusts its speed using Auto Mode
settings.
Î
Manual Mode
The fan spins at the speed set in Manual Mode
settings.
Î Fan start/off temperature
Use the + or – key to change the Fan start/off temperature value. Enter a decimal
number between 1 and 100.
Î Fan start PWM
Use the + or – key to change the Fan start PWM value. Enter a decimal number between
1 and 100.
Î Fan slope PWM
Use the + or – key to change the Fan slope PWM value. Enter a decimal number between
1 and 8.
5.3.9 Serial Port Console Redirection
The Serial Port Console Redirection menu (BIOS Menu 15) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
