WSB-H810 PICMG 1.0 CPU Card
Page 67
Options Description
+5V DUAL +5V dual (default)
+5V +5V
Table 4-4: USB Power Source Setup
Please refer to Section 5.4.1 for detailed information.
4.10 Chassis Installation
4.10.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the WSB-H810 must have air vents
to allow cool air to move into the system and hot air to move out.
The WSB-H810 must be installed in a chassis with ventilation holes on the sides allowing
airflow to travel through the heat sink surface. In a system with an individual power supply
unit, the cooling fan of a power supply can also help generate airflow through the board
surface.
4.10.2 CPU Card Installation
To install the CPU card onto the backplane, carefully align the CPU card edge connector
with the CPU card socket on the backplane. To do this, please refer to the reference
material that came with the backplane. Next, secure the CPU card to the chassis. To do
this, please refer to the reference material that came with the chassis.
