WSB-H810 PICMG 1.0 CPU Card

Page 37

Pin Description Pin Description

13 N/C 14

N/C

15 GND 16

N/C

17 N/C 18

GND

19 N/C 20

WLAN_EN

21 GND 22

PLTRST_N

23 PCIE_RX- 24

+3.3V

25 PCIE_RX+ 26

GND

27 GND 28

1.5V

29 GND 30

SMB_CLK

31 PCIE_TX- 32

SMB_DATA

33 PCIE_TX+ 34

GND

35 GND 36

USB_D-

37 GND 38

USB_D+

39 +3.3V 40

GND

41 +3.3V 42

N/C

43 +3.3V 44

N/C

45 N/C 46

N/C

47 N/C 48

1.5V

49 N/C 50

GND

51 N/C 52

+3.3V

Table 3-21: PCIe Mini Slot Pinouts

3.2.20 SATA 3Gb/s Drive Connector

CN Label: S_ATA3

CN Type:

7-pin SATA drive connector

CN Location:

See

Figure 3-21

CN Pinouts:

See

Table 3-22

The SATA drive connector can be connected to SATA drive and supports up to 3Gb/s

data transfer rate.
