WSB-H810 PICMG 1.0 CPU Card
Page 19
3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
+12V power connector 4-pin Molex power
connector
CPU12V1
ATX power supply enable connector 3-pin wafer ATXCTL1
Audio kit connector 10-pin header J_AUDIO1
Battery connector 2-pin wafer BAT1
Chassis intrusion connector 2-pin header CHASSIS1
DDR3 DIMM sockets 240-pin socket CHA_DIMM1
CHB_DIMM1
Digital I/O connector 10-pin header DIO1
EC debug connector 18-pin header CN3
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system) 3-pin wafer SYS_FAN1
Front panel connector 14-pin header F_PANEL1
I
2
C connector 4-pin wafer CN1
Infrared connector (reserved) 5-pin header IR1
Internal DisplayPort connector 19-pin box header DP1
Keyboard and mouse connector 6-pin wafer KB_MS1
LAN LED connectors 2-pin header
LED_LAN1,
LED_LAN2
mSATA slot PCIe Mini MSATA1
Parallel port connector 26-pin box header LPT1
PCIe Mini slot PCIe Mini MPCIE1
SATA 3Gb/s drive connector 7-pin SATA connector SATA_3
SATA 6Gb/s drive connectors 7-pin SATA connector S_ATA1, S_ATA2,
