WSB-H810 PICMG 1.0 CPU Card

Page 114

6.1 Available Software Drivers

NOTE:

The content of the CD may vary throughout the life cycle of the product

and is subject to change without prior notice. Visit the IEI website or

contact technical support for the latest updates.

The following drivers can be installed on the system:

 Chipset

 Graphics

 LAN

 Audio

 USB 3.0

Installation instructions are given below.

6.2 Software Installation

All the drivers for the WSB-H810 are on the CD that came with the system. To install the

drivers, please follow the steps below.

Step 1: Insert the CD into a CD drive connected to the system.

NOTE:

If the installation program doesn't start automatically:

Click "Start->My Computer->CD Drive->autorun.exe"

Step 2: The driver main menu appears.

Step 3: Click WSB-H810.

Step 4: A new screen with a list of available drivers appears.

Step 5: Install all of the necessary drivers in the menu.
