WSB-H810 PICMG 1.0 CPU Card
Page 48
LED Description LED Description
A on: linked
blinking: data is being sent/received
B off: 10 Mb/s
green: 100 Mb/s
orange: 1000 Mb/s
Table 3-35: Connector LEDs
3.3.2 USB 2.0 Connectors
CN Label:
USB2-1 and USB2-2
CN Type:
USB port
CN Location:
See Figure 3-32
CN Pinouts:
See Table 3-36
The WSB-H810 has two external USB 2.0 ports. The ports connect to both USB 2.0 and
USB 1.1 devices.
Pin Description
1 VCC
2 DATA-
3 DATA+
4 GROUND
Table 3-36: USB 2.0 Port Pinouts
3.3.3 VGA Connector
CN Label: VGA1
CN Type:
15-pin female
CN Location:
See Figure 3-32
CN Pinouts:
See Figure 3-34 and Table 3-37
