WSB-H810 PICMG 1.0 CPU Card
Page 81
5.3.5 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
SATA Controller(s) [Enabled]
SATA Mode Selection [IDE]
SATA Test Mode [Enabled]
Aggressive LPM Support [Enabled]
SATA Controller Speed [Default]
SATA1 Port Empty
Software Preserve Unknown
SATA2 Port Empty
Software Preserve Unknown
SATA3 Port Empty
mSATA Port Empty
Enable or disable SATA
Device.
---------------------
ÆÅ
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
Î SATA Controller(s) [Enabled]
Use the SATA Controller(s) option to configure the SATA controller(s).
Î
Enabled DEFAULT
Enables the on-board SATA controller(s).
Î
Disabled
Disables the on-board SATA controller(s).
Î SATA Mode Selection [IDE]
Use the SATA Mode Selection option to determine how SATA devices operate.
Î
IDE DEFAULT
Configures SATA devices as normal IDE device.
Î
AHCI
Configures SATA devices as AHCI device.
Î SATA Test Mode [Enabled]
Use the SATA Test Mode option to enable or disable the SATA test mode.
