WSB-H810 PICMG 1.0 CPU Card

Page 82

Enabled DEFAULT

Enables the SATA test mode.

Disabled

Disables the SATA test mode.

Î Aggressive LPM Support [Enabled]

Use the Aggressive LPM Support option to enable or disable the PCH to aggressively

enter link power state.

Enabled DEFAULT

Enables the PCH to aggressively enter link power state.

Disabled

Disables the PCH to aggressively enter link power state.

Î SATA Controller Speed [Default]

Use the SATA Controller Speed option to specify the maximum speed the SATA

controller can support.

 Default Default

 Gen1

 Gen2

 Gen3

User Manual1
