WSB-H810 PICMG 1.0 CPU Card
Page 92
Î
IO=278h;
IRQ=5, 7
Parallel Port I/O port address is 278h and the
interrupt address is IRQ5, 7
Î
IO=3BCh;
IRQ=5, 7
Parallel Port I/O port address is 3BCh and the
interrupt address is IRQ5, 7
Î Device Mode [STD Printer Mode]
Use the Device Mode option to select the mode the parallel port operates in.
Configuration options are listed below.
STD Printer Mode Default
SPP Mode
EPP-1.9 and SPP Mode
EPP-1.7 and SPP Mode
ECP Mode
ECP and EPP 1.9 Mode
ECP and EPP 1.7 Mode
5.3.8 iWDD H/W Monitor
The iWDD H/W Monitor menu (BIOS Menu 13) contains the fan configuration submenu
and displays operating temperature, fan speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU temperature :+44ºC
System temperature :+34ºC
CPU_FAN1 Speed :1883 RPM
SYS_FAN1 Speed :N/A
CPU_CORE :+1.746 V
+5V :+5.131 V
+12V :+11.903 V
DDR :+1.513 V
+5VSB :+4.991 V
+3.3V :+3.296 V
+3.3VSB :+3.306 V
Smart Fan Mode Select
---------------------
ÆÅ
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 13: iWDD H/W Monitor
