5.4.1 PCH-IO Configuration
Use the PCH-IO Configuration menu (BIOS Menu 18) to configure the PCH parameters.
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disable (ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCH Azalia Configuration
Power Saving Function(ERP) [Disabled]
USB Power SW1 [+5V DUAL]
USB Power SW2 [+5V DUAL]
Select AC power state
when power is re-applied
after a power failure.
---------------------
ÆÅ
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 18: PCH-IO Configuration
Î Restore AC Power Loss [Last State]
Use the Restore AC Power Loss BIOS option to specify what state the system returns to
if there is a sudden loss of power to the system.
Î
Power Off
The system remains turned off
Î
Power On
The system turns on
Î
Last State DEFAULT
The system returns to its previous state. If it was on, it
turns itself on. If it was off, it remains off.
Î Power Saving Function(ERP) [Disabled]
Use the Power Saving Function(ERP) BIOS option to enable or disable the power
saving function.
Î
Disabled DEFAULT
Power saving function is disabled.
Î
Enabled
Power saving function is enabled. It will reduce power
consumption when the system is off.
