5.4.2.2 NB PCIe Configuration
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
NB PCIe Configuration
PEG0 Not Present
PEG0 – Gen X [Auto]
Enable PEG [Auto]
Detect Non-compliance Device [Disabled]
onfigure PEG0 B0:D1:F0
Gen1-Gen2
----------------------
ÆÅ
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 25: NB PCIe Configuration
Î PEG0 – Gen X [Auto]
Use the PEG0 – Gen X option to select the support type of the PCI Express slot. The
following options are available:
Auto Default
Gen1
Gen2
Î Enable PEG [Auto]
Use the Enable PEG option to enable or disable the PCI Express (PEG) controller.
Î
Disabled
Disables the PCI Express (PEG) controller.
Î
Enabled
Enables the PCI Express (PEG) controller.
Î
Auto DEFAULT
The PCI Express (PEG) controller is disabled if no
PCI Express devices are connected.
Î Detect Non-Compliance Device [Disabled]
Use the Detect Non-Compliance Device option to enable or disable detecting if a
non-compliance PCI Express device is connected to the PCI Express port.
