WSB-H810 PICMG 1.0 CPU Card
Page 8
1.6 Technical Specifications
The WSB-H810 technical specifications are listed below.
Specification/Model WSB-H810
Form Factor
PICMG 1.0
CPU Supported
4th generation LGA1150 Intel® Core™ i7/i5/i3, Pentium®
or Celeron® CPU
PCH
Intel® H81
Memory
Two 240-pin 1600/1333 MHz dual-channel unbuffered
DDR3/DDR3L SDRAM DIMMs support up to 16 GB
Graphics Engine
Intel® HD Graphics Gen 7.5 supports DirectX 11.1,
OpenCL 1.2, OpenGL 3.2, Full MPEG2, VC1, AVC Decode
Display Output
Dual independent display
One VGA (up to 1920x1200@60 Hz)
One iDP interface for HDMI, LVDS, VGA, DVI and
DisplayPort (up to 3840x2160@60 Hz)
Ethernet Controllers
LAN1: Intel® I217-LM Ethernet controller
LAN2: Intel® I211-AT Ethernet controller
Audio
Supports 7.1 channel HD Audio by IEI AC-KIT-892HD kit
BIOS
UEFI BIOS
Super I/O Controller
Fintek F81866
Watchdog Timer
Software programmable supports 1~255 sec. system reset
Expansion
One PCIe Mini slot
One mSATA slot (SATA 3Gb/s signal)
PCI signal and ISA signal via golden finger
I/O Interface Connectors
Audio Connector
One internal audio connector (10-pin header)
Chassis Intrusion
One 2-pin header
Digital I/O
8-bit digital I/O
