WSB-H810 PICMG 1.0 CPU Card
Page 9
Specification/Model WSB-H810
Ethernet
Two RJ-45 GbE ports
Fan
One 4-pin smart fan connector (CPU fan)
One 3-pin smart fan connector (system fan)
Front Panel
One 14-pin header (power LED, HDD LED, speaker, power
button, reset button)
I
2
C
One 4-pin wafer connector
Infrared (Reserved)
One via 5-pin header
Keyboard and Mouse
One 6-pin wafer connector
LAN LEDs
Two 2-pin headers
Parallel Port
One parallel port via internal 26-pin box header
Serial ATA
Two SATA 6Gb/s connectors (support AHCI, no RAID)
One SATA 3Gb/s connector (supports AHCI, no RAID)
Serial Ports
Four RS-232 via internal box headers
One RS-422/485 via internal 4-pin wafer connector
SMBus
One 4-pin wafer connector
TPM
One via 20-pin header
USB Ports
Two USB 3.0 ports by pin header
Two USB 2.0 ports on rear IO
Four USB 2.0 ports by two pin headers
One USB 2.0 port by internal Type A connector
Environmental and Power Specifications
Power Supply
5V/12V, AT/ATX power supported
Power Consumption
5V@3.4A , 12V@0.36A, Vcore_12V@7.48A, 3.3V@1.42A,
5VSB@0.13A (3.9 GHz Intel® Core i7-4770K CPU with
two 4 GB 1333 MHz DDR3 memory)
Operating Temperature
-20ºC ~ 60ºC
Storage Temperature
-30ºC ~ 70ºC
Humidity
5% ~ 95% (non-condensing)
