5.3.7.3 Parallel Port Configuration
Use the Parallel Port Configuration menu (BIOS Menu 12) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=5
Change Settings [Auto]
Device Mode [STD Printer Mode]
Enable or Disable
Parallel Port (LPT/LPTE)
---------------------
ÆÅ : Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
BIOS Menu 12: Parallel Port Configuration Menu
Î Parallel Port [Enabled]
Use the Parallel Port option to enable or disable the parallel port.
Î
Disabled
Disable the parallel port
Î
Enabled DEFAULT
Enable the parallel port
Î Change Settings [Auto]
Use the Change Settings option to change the parallel port IO port address and interrupt
address.
Î
Auto DEFAULT
The parallel port IO port address and interrupt
address are automatically detected.
Î
IO=378h;
IRQ=5
Parallel Port I/O port address is 378h and the
interrupt address is IRQ5
Î
IO=378h;
IRQ=5, 7
Parallel Port I/O port address is 378h and the
interrupt address is IRQ5, 7
