WSB-H810 PICMG 1.0 CPU Card
Page 85
5.3.7.1.1 Serial Port 1 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled
Disable the serial port
Î
Enabled DEFAULT
Enable the serial port
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.
Î
IO=3F8h;
IRQ=4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ4.
Î
IO=3F8h;
IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4.
Î
IO=2C0h;
IRQ=3, 4
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ3, 4.
Î
IO=2C8h;
IRQ=3, 4
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ3, 4.
5.3.7.1.2 Serial Port 2 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled
Disable the serial port
Î
Enabled DEFAULT
Enable the serial port
