IEI Technology WSB-H810 User Manual

WSB-H810 PICMG 1.0 CPU Card
Page 86
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.
Î
IO=2F8h;
IRQ=3
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3.
Î
IO=3F8h;
IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4.
Î
IO=2F8h;
IRQ=3, 4
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4.
Î
IO=2C0h;
IRQ=3, 4
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ3, 4.
Î
IO=2C8h;
IRQ=3, 4
Serial Port I/O port address is 2C8h and the interrupt
address is IRQ3, 4.
Î Device Mode [RS422/485]
Use the Device Mode option to select the serial port mode.
Î
RS422/485 DEFAULT
Enables serial port RS-422/485 support.
5.3.7.1.3 Serial Port 3 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled
Disable the serial port
Î
Enabled DEFAULT
Enable the serial port
