WSB-H810 PICMG 1.0 CPU Card

Page 110

Î Quiet Boot [Enabled]

Use the Quiet Boot BIOS option to select the screen display when the system boots.

Disabled

Normal POST messages displayed

Enabled DEFAULT

OEM Logo displayed instead of POST messages

Î Option ROM Messages [Force BIOS]

Use the Option ROM Messages option to set the Option ROM display mode.

Force

BIOS

DEFAULT

Sets display mode to force BIOS.

Keep

Current

Sets display mode to current.

Î Launch PXE OpROM [Disabled]

Use the Launch PXE OpROM option to enable or disable boot option for legacy network

devices.

Disabled DEFAULT

Ignore all PXE Option ROMs

Enabled

Load PXE Option ROMs.

Î UEFI Boot [Disabled]

Use the UEFI Boot option to enable or disable to boot from the UEFI devices.

Enabled

Boot from UEFI devices is enabled.

Disabled DEFAULT

Boot from UEFI devices is disabled.
