Infors Multitron - External Cooling; Direct Steam Humidification

Multitron - Incubation Shaker
Technical Data and Specifications
Page 136 of 146 25 February 2019
12.4.2 External Cooling
Specifications for the connection / water quality
Description
Value
Unit
Connection (hose Ø)
10
mm
Input pressure
max. 4.0
bar
Water hardness
< 0.01, CaCO
3
equivalent
mmol/L
Water conductivity
min. 5 / max. 20
μS/cm
Dissolved solids
< 10
mg/L
ATTENTION
The installed valve regulates the temperature by closing and
opening the cycle. Hence it can be necessary to install a bypass
from the inlet to the outlet to protect the circulation pump against
damage.
12.4.3 Direct Steam Humidification
Casing dimensions
Description
Value
Unit
Height
340
mm
Depth
80
mm
Width
200
mm
Various
Description
Value
Unit
Additional mass
3
kg
Water consumption
1
8.3
g/h
Temperature range for use
2
Up to 40
°C
Heating time of the unit
5
min
1
) At an ambient temperature of up to 20 °C and at a temperature of 37 °C and
relative humidity of 85 % in the incubation chamber.
2
) Temperature in the interior at which functioning can be guaranteed
