Multitron - Incubation Shaker
Setup and Function
Page 26 of 146 25 February 2019
Variable throw
If the equipment features a variable throw, there are four possible
positions for the eccentric throw:
12.5 mm
19 mm
25 mm
50 mm
The counterweights are also adjustable to reduce vibrations during
operation.
The throw may only be adjusted by personnel that has received
appropriate training and authorisations. If in doubt, contact In-
fors (see contact details on page 2).
Operation
The Rotation speed parameter is operated via the operating panel.
Beside the actual value, the symbol RPM and the unit min
-1
on the display.
For an exact description of how to set the parameters, see chapter
7.4 "Adjusting, Activating and Deactivating Parameters", page 81.
The permissible load weights depend on the position of the
equipment in the stack, the throw and the shaking speed (see
chapter 12.3.1 "Rotation Speed Parameter (Shaker Drive)",
Technical data and setpoints
For a detailed description of the technical data and possible maxi-
mum rotation speeds, see chapter 12.3.1 "Rotation Speed Param-
eter (Shaker Drive)", page 132.
