Multitron - Incubation Shaker
Accessories
Page 54 of 146 25 February 2019
Tray with clamping assemblies tilted at an angle of 20° (angled in-
cubation):
The tilted clamping assembly is a wedge-shaped metal sheet with
two profiles. The lower profile is an angled bar (3). The upper pro-
file is a U profile into which the cellular rubber string (2) is inserted.
There are two spacers on the upper edge (1) for positioning the mi-
crotitre plates or deep-well plates.
The trays with clamping assemblies are designed for microtitre and
deep-well plates with dimensions 85.1 mm x 127 mm. To ensure
sufficient clamping force can be achieved, plates with a web height
of at least 3 mm must be used.
Technical Data for Clamping Assemblies
Rail material Aluminium
Mild neutral cleaning agent
Commercially available disin-
fectant
Sterilisation NO
Size of microtitre and deep-well
plates
85.1 x 127 mm
1
2
3
