Multitron - Incubation Shaker
Accessories
25 February 2019 Page 53 of 146
Technical data for pin holders
Cleaning Mild neutral cleaning agent
Disinfection
Commercially available disin-
fectant
Sterilisation in autoclaves
External dimensions of the
microtitre plates
Height of the deep well plates 42 mm
Tray with clamping assembly
There is a quick clamping assembly for affixing microtitre and
deep-well plates. Two versions of this clamping assembly are
available:
Tray with flat clamping assembly (horizontal incubation):
The flat clamping assembly is a profile made of sheet metal that is
equipped with an angled strip (2). On the other side, there is an
edge featuring a foam rubber strip (3). There are two spacers on
the edge (1) for positioning microtitre plates or deep-well plates.
2
1
3
