Chapter 4 Quick setup 54
Parameters description
Name
Description
Peer AP1
It specifies the wireless network name (SSID) of the peer AP1.
MAC Address of
Peer AP1
It specifies the MAC address of the wireless network to be bridged.
Channel
It specifies the operating channel of the WiFi network to be bridged. It will be
automatically populated when you select an SSID to bridge.
Security Mode
It specifies the security mode of the WiFi network to be bridged. It will be
automatically populated when you select an SSID to bridge.
Tip
The Repeater mode only supports WEP and None security modes.
(6) Set the IP address to an unused IP address belonging to the same network segment as
that of CPE1. Then set the Subnet Mask to the same one of the CPE1 and click Next.
For example, if the IP address of CPE1 is 192.168.2.1, you can set this device’s IP address
to 192.168.2.X (X ranges from 2 to 254).
*
*
*
*
*
*
