Chapter 4 Quick setup 56

The bridging is successful when the ping succeeds.

Peer to multiple peers bridging

Assume that the related parameters are shown as follows:

CPE1:

− IP Address: 192.168.2.1

− SSID: IP-COM_1

CPE1: Repeater mode

CPE2: Repeater mode

Switch

Router

CPE3: Repeater mode

Switch

Internet

WAN

LAN

Computer

IP camera

NVR
