JAC T9 - Air Volume Adjustment; Automatic Air Conditioning

178
A/C and infotainment system
1. A/C system ON/OFF
2. Air internal and external
circulation adjustment
3. Air volume adjustment
4. Air outlet mode adjustment
5. Automatic air conditioning
6. A/C compressor ON/OFF
Click the button, start the
A/C system, and restore
by default the latest state
before turning o.
Click the icon to switch
to the air circulation
mode. When the icon is
presented as , it
indicates that the external
air circulation mode is enabled so that the
air out of the vehicle can be guided into the
vehicle. When the icon is presented as
, it indicates that the air internal
circulation mode is enabled.
Adjust the air volume
of A/C. The air volume
increases as the number
increases until reaching
Gear 8 which is the
highest level.
Click to change the air
outlet mode of A/C.
There are 5 modes:
Click the icon to
enable the A/C mode
automatically. Select
proper temperature as
personal need. The air
conditioning system will automatically
adjust air-out mode and air volume to
achieve the setting temperature.
Click the icon to turn on
or o the A/C compressor.
The A/C compressor is
used for cooling.
Notice
Notice
● In most of the cases, the external
circulation mode shall be prioritized.
Use of internal circulation mode
tends to cause foggy windows,
especially when the compressor is
turned o.
● The internal circulation mode shall
be enabled under such circumstances
as the tunnel, trac jam, dirty air
outside the vehicle or quick cooling
and heating desired.
Symbol Mode
Air blows to the upper body of
passenger.
Air blows to the upper body
and foot of passenger.
Air blows to the foot.
Air blows to the front
windshield and foot.
Air blows to the front
windshield.
1
1
2
AUTO
A/C
