Juniper EX4300 Series

Table 67: QSFP+ and QSFP28 Network Port Connector Pinout Informaon (Connued)
Pin Signal
16 GND
17 RX1p
18 RX1n
19 GND
20 GND
21 RX2n
22 RX2p
23 GND
24 RX4n
25 RX4p
26 GND
27 ModPrsL
28 IntL
29 VccTx
30 Vcc1
