Juniper EX4300 Series

Table 62: RJ-45 Management Port Connector Pinout Informaon (Connued)
Pin Signal Descripon
3 TRP2+ Transmit/receive data pair 2
4 TRP3+ Transmit/receive data pair 3
5 TRP3- Transmit/receive data pair 3
6 TRP2- Transmit/receive data pair 2
7 TRP4+ Transmit/receive data pair 4
8 TRP4- Transmit/receive data pair 4
EX4300 RJ-45 Port, SFP Port, SFP+ Port, QSFP+ Port, and QSFP28 Port
Connector Pinout Informaon
The tables in this topic describe the connector pinout informaon for the RJ-45, QSFP+, QSFP28, SFP+,
and SFP ports.
• Table 63 on page 156—10/100/1000BASE-T Ethernet network port connector pinout informaon
except for EX4300-48MP and EX4300-48MP-S switches
• Table 64 on page 156—10/100/1000BASE-T Ethernet network port and
100/1000/2500/5000/10000BASE-T Ethernet network port connector pinout informaon for
EX4300-48MP and EX4300-48MP-S switches
• Table 65 on page 158—SFP network port connector pinout informaon
• Table 66 on page 159—SFP+ network port connector pinout informaon
• Table 67 on page 161—QSFP+ and QSFP28 network module ports connector pinout informaon
155
