In EX4300-48MP and EX4300-48MP-S switches, you can use only the built-in QSFP+ ports as VCPs.
You cannot congure the ports on the uplink module in EX4300-48MP and EX4300-48MP-S
switches to Virtual Chassis ports (VCPs).
• On QFX3500 and QFX3600, all non-channelized QSFP+ and xed SFP+ interfaces.
BEST PRACTICE: Use the 40-Gigabit QSFP+ interfaces for the VCPs.
The advantages of connecng mulple switches into a Virtual Chassis include beer-managed
bandwidth at a network layer, simplied conguraon and maintenance because mulple devices can be
managed as a single device, increased fault tolerance and high availability (HA) because a Virtual Chassis
can remain acve and network trac can be redirected to other member switches when a single
member switch fails, and a aer, simplied Layer 2 network topology that minimizes or eliminates the
need for loop prevenon protocols such as Spanning Tree Protocol (STP).
You can increase VCP bandwidth between member switches by conguring mulple interfaces between
the same two switches into VCPs. When mulple VCPs are interconnecng the same two member
switches, a Link Aggregaon Group (LAG) bundle is automacally formed when the VCPs are on
interfaces supporng idencal speeds. For instance, if you have two 40-Gigabit QSFP+ interfaces
congured as VCPs between member switches, a LAG with two member links with 80 Gbps of total
bandwidth is formed. 10-Gigabit SFP+ and 40-Gigabit QSFP+ interfaces congured as VCPs cannot be
members of the same LAG, however. The Virtual Chassis feature is not applicable to QFX devices in a
QFabric.
Virtual Chassis can be installed in a single rack, mulple racks, or in wire closets.
Valid Conguraons
Valid conguraons are:
• All QFX5100 members–in a ring topology this is Virtual Chassis; in a spine and leaf topology this is a
Virtual Chassis Fabric (VCF). For a cabling example of spine and leaf, see Connecng a QFX5100
Device in a Virtual Chassis Fabric.
• All QFX3600 members
• All QFX3500 members
• A mixture of QFX3600 and QFX3500 members
• A mixture of QFX5100, QFX3600, and QFX3500 members–use the QFX5100 switches as primary
and backup whenever possible.
215

Juniper EX4300 Series Specifications

General

Product Series	EX4300 Series
Power Consumption	Varies by model and configuration
Virtual Chassis Technology	Up to 10 switches
Software	Junos OS
Ports	24-port and 48-port models
10GBASE SFP+ Ports	Up to 8 ports
40GBASE QSFP+ Ports	2
Uplink Ports	Up to 4 ports
Jumbo Frames	Up to 9216 bytes
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 90% noncondensing
Input Voltage	100 to 240V AC
Power Supply	AC or DC
Power Supply Options	AC or DC
Stacking	Yes
Layer 2 Features	Includes VLAN, STP, RSTP, MSTP, LACP
Layer 3 Features	OSPF, BGP
Management	CLI, Web GUI, SNMP
Security Features	DHCP snooping
QoS	8 queues per port, DSCP
Storage Temperature	-40°C to 70°C
