Juniper EX4300 Series

Table 70: Parts Required for Connecng an EX Series Switch to Earth Ground (Connued)
Switch Earthing
Terminal
Locaon
Grounding
Cable
Requirements
Grounding Lug
Specicaons
Screws and
Washers
Addional
Informaon
EX4300
switches
except
EX4300-4
8MP and
EX4300-4
8MP-S
switches
Rear panel of
the chassis
14-10 AWG
STR (2.5-6
mm²), minimum
90° C wire, or
as permied by
the local code
Panduit
LCD10-10A-L or
equivalent—
not provided
• Two 10-32
x .25 in.
screws with
#10 split-
lock washer
—
not provided
• Two #10 at
washers—
not provided
EX4300-4
8MP and
EX4300-4
8MP-S
switches
Rear panel of
the chassis
14-10 AWG
STR (2.5-6
mm²), minimum
90° C wire, or
as permied by
the local code
Panduit
LCD10-14B-L,
LCC10-BW-L, or
equivalent—
not provided
• Two 10-32
x .25 in.
screws with
#10 split-
lock washer
—
not provided
• Two #10 at
washers—
not provided
EX4500
and
EX4550
Le side of
the chassis
14 AWG
(2 mm²),
minimum 90° C
wire, or as
permied by
the local code
Panduit
LCC10-14BWL or
equivalent—
not provided
• Two 10-32
x .25 in.
screws with
#10 split-
lock washer
—
not provided
• Two #10 at
washers—
not provided
See "Special
Instrucons to
Follow Before
Connecng Earth
Ground to an EX
Series Switch" on
page 193.
190
