Table 75: Health Status (Connued)
Field Descripon
Fan Status Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent.
Capacity Ulizaon Panel
Table 76: Capacity Ulizaon
Field Descripon
Number of acve ports Indicates the number of acve ports in the switch.
Congured Virtual Chassis ports (VCPs) are considered
as acve ports.
Total number of ports Indicates the number of ports in the switch.
In EX3300 Virtual Chassis, the total number of ports of
all of the switches is displayed.
For EX4650 switches, on loading the switch, the
consolidated values for all the FPCs are displayed by
default.
For EX4400, EX4100, and EX4100-F switches, on
loading the switch, the consolidated values for all the
FPCs are displayed by default and dedicated VCP ports
are not considered.
Used-up MAC-Table entries Indicates the number of MAC table entries.
