Keithley 2110 User Manual

Model 2110
5½ Digit Multimeter Reference Manual Section 2:
General overview
2110-901-01 Rev. C/August 2013 2-13
Keys, menus, and selection Description
SHIFT
Press the SHIFT key to access the shifted function for the next key
you press.
DCV (DCI)
Press the DCV (DCI) key.
CONFIG
Press the CONFIG key to configure DC current measurements.
NPLC
Use ► and ◄ keys to select resolution adjustment. Refer to
Resolution and integration time (on page 3-41) for information about
the number of power line cycles (NPLC).
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
ACV (ACI)
Press the ACV (ACI) key.
CONFIG
Press the CONFIG key to configure the instrument for AC current
measurements.
BAND WIDTH
Use ► and ◄ keys to select bandwidth. Refer to Bandwidth and
resolution for AC measurements (on page 3-44) for details.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
Ω2 (Ω4)
Press the Ω2 (Ω4) key.
CONFIG
Press the CONFIG key to configure the instrument for resistance
measurements.
NPLC
Use ► and ◄ keys to select resolution adjustment. Refer to
Resolution and integration time (on page 3-41) for information about
the number of power line cycles (NPLC).
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
FREQ ( )
Press FREQ ( ) key.
CONFIG
Press the CONFIG key to configure the instrument for capacitance
measurements.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
RANGE AUTO
Use ► and ◄ keys to select RANGE AUTO (autorange) or use
► and ◄ keys to display additional selections.
CONT
( )
Press CONT ( ) key.
CONFIG
Press the CONFIG key to configure the instrument for diode
measurements.
VF-LOW
Refer to Diode measurements (on page 3-15) for details.
VF-HI
TEMP (TCOUPL)
Press TEMP (TCOUPL) key.
CONFIG
Press the CONFIG key to configure the instrument for thermocouple
measurements.
TYPE
Refer to Thermocouple measurements (on page 3-22) for details.
UNITS
Specify units for temperature measurement (C, F or K).

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
