Keithley 2110 User Manual

Section
2: General overview Model 2110 5½ Digit Multimeter
Reference Manual
2-14 2110-901-01 Rev. C/August 2013
Keys, menus, and selection Description
ENTER (2ND)
Press ENTER (2ND) key.
CONFIG
Refer to Secondary measurement function (on page 3-26) for
details.
OFF
Select OFF to turn off the dual measurement function off.
DCV
Select DCV to configure DC voltage as the second function.
DCI
Select DCI to configure DC current as the second function.
NPLC
Use ► and ◄ keys to select resolution adjustment. Refer to
Resolution and integration time (on page 3-41) for information about
the number of power line cycles (NPLC).
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
2W RES
Select 2W RES to configure 2-wire resistance as the second
function.
NPLC
Use ► and ◄ keys to select resolution adjustment. Refer to
Resolution and integration time (on page 3-41) for information about
the number of power line cycles (NPLC).
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
4W RES
Select 4W RES to configure 4-wire resistance as the second
function.
NPLC
Use ► and ◄ keys to select resolution adjustment. Refer to
Resolution and integration time (on page 3-41) for information about
the number of power line cycles (NPLC).
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
ACV
Select ACV to configure AC voltage as the second function.
BAND WIDTH
Use ► and ◄ keys to select bandwidth. Refer to Bandwidth and
resolution for AC measurements (on page 3-44) for details.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
ACI
Select ACI to configure AC current as the second function.
BAND WIDTH
Use ► and ◄ keys to select bandwidth. Refer to Bandwidth and
resolution for AC measurements (on page 3-44) for details.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
FREQ
Select FREQ to configure frequency as the second function.
APERTURE
Refer to Aperture and resolution for frequency and period
measurements (on page 3-45) for details.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
PERIOD
Select PERIOD to configure period as the second function.
APERTURE
Refer to Aperture and resolution for frequency and period
measurements (on page 3-45) for details.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
CURR FREQ
Select CURR FREQ to configure frequency as the second function.
APERTURE
Refer to Aperture and resolution for frequency and period
measurements (on page 3-45) for details.
RANGE
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
CURR PERIOD
Select CURR PERIOD to configure current period as the second
function.
APERTURE
Refer to Aperture and resolution for frequency and period
measurements (on page 3-45) for details.

Keithley 2110 Specifications

General

Model	2110
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Continuity	Yes
Diode Test	Yes
Category	Digital Multimeter
Display	5.5 digit
DC Current Range	100 µA to 3 A
AC Current Range	100 µA to 3 A
Resistance Range	100 MΩ
Frequency Range	3 Hz to 300 kHz
Frequency Accuracy	0.01% + 1 count
Capacitance Range	1 nF to 100 µF
Capacitance Accuracy	1% + 5 counts
Connectivity	USB, GPIB (optional)
Dimensions	88 mm
Power Supply	100 V to 240 V AC, 50/60 Hz
DC Voltage Accuracy	±0.012% + 2 counts
