2110 5½ Digit Multimeter Reference Manual Section 2:
2110-901-01 Rev. C/August 2013 2-15
Keys, menus, and selection Description
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
Select CAP to configure capacitance as the second function.
Use ► and ◄ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
Select TEMP to configure temperature as the second function.
Select the RTD sensor type. Use ► and ◄ keys to display
Specify units for temperature measurement (C, F, or K).
Select the temperature transducer type (2-wire RTD or 4-wire RTD).
Select TCOUPL to configure thermocouple as the second function.
Select TYPE to configure the thermocouple type.
Specify units for temperature measurement (C, F, or K).
Specify reference junction type, real or simulated (REAL or
Select VIEW REAL to view the temperature of the internal reference
junction.
Press TRIGGER (AUTO/HOLD) to toggle the reading hold function
on and off. Refer to Reading hold (on page 3-35) for details.
Press
to view stored readings. Refer to Data
buffer (on page 3-36) for details.
Press DIGITS (FILTER) to select the type of filter for the
measurement on the selected function, or to turn the filter off. Use
► and ◄ keys to display additional selections. Refer to Digital filter
(on page 3-47) for details about moving average and repeat
Select to configure MOVING AVERAGE. Use ► and ◄ keys to
display additional selections.
Select RUN to start the function.
Enter the number of readings using ▲ ▼ ► ◄ keys.
Select to configure REPEAT AVERAGE. Use ► and ◄ keys to
display additional selections.
Select RUN to start the function.
Enter the number of readings using ▲ ▼ ► ◄ keys.
