5.2.14.1. Terminal blocks (AC Satellite with charging cables)
See also 10: Examples of connecting output and control cables to charging
points and 11: Examples of connecting cables to the Satellites.
Figure 48. Terminal blocks in the double AC Satellite with charging cables
1 Power supply 5 Circuit breaker
2 Residual current monitor (RCM) 6 Terminal blocks for AC supply
power cables (2 x 50 mm
2
screw
terminal)
3 Contactor 7 Terminal blocks for PE wires
4 kWh meter
CHARGING EQUIPMENT FOR ELECTRIC VEHICLES INSTALLATION MANUAL
CONFIDENTIAL – CERTIFIED PARTNERS 104 REV 2.40 EN 04-2024
