Legend Description
3 Local Area Network (LAN) interface connector
4 AC power connector
5 Ventilation fan
6 Instrument serial number and MAC address
7 Instrument safety and regulatory labels
This is a Protection Class 1 equipment (chassis must be connected to a protective earth ground). The mains plug
shall only be inserted in an outlet provided with a Protective Earth Terminal.
Instrument Dimensions
Height: 164.70 mm x Width: 313.60 mm
Keysight EDU33210 Series User's Guide
21
