8 Commissioning/Shutdown
124 of 212
PumpDrive 2
Analog inputs on the I/O extension board
The I/O extension board has an additional analog input. A signal type and function
must be selected for the analog input. The measuring range is scaled for the signal
selected by setting a defined upper and lower limit. (ðSection8.10.2,Page118)
NOTE
The parameter values and value ranges/units entered are mutually dependent. This
is why the first step in parameterising the frequency inverter is always to specify the
applicable value range and units (3-11). If the value range or unit is subsequently
changed, all dependent parameters must be checked for correctness again.
Table98: Parameters for analog input 3
Parameter Description Possible settings Factory setting
3-8-3-1 Analog Input3 Signal
Sensor signal at analog input3
▪ OFF
▪ 4…20mA
▪ 2…10V
▪ 0…20mA
▪ 0…10V
OFF
3-8-3-2 Analog Input 3 Function
Function of analog input3. Internal
operating values cannot be used as an
actual value source.
▪ OFF
▪ Setpoint/Control Value
(Auto)
▪ Control Value (Manual)
▪ Suction Pressure
▪ Discharge Pressure
▪ Differential Pressure
▪ Flow Rate
▪ Level
▪ Temperature
▪ Suction Pressure_Internal
▪ Discharge Pressure_Internal
▪ Differential
Pressure_Internal
OFF
3-8-3-3 Analog Input 3 Lower Limit Minimum limit of measuring
range (dependent on the analog
input function selected)
0
3-8-3-4 Analog Input 3 Upper Limit Maximum limit of measuring
range (dependent on the analog
input function selected)
0
Relay outputs on the I/O extension board
The I/O extension board has one volt-free (NO/NC) relay and five volt-free (NO) relays.
The function of the relays can be parameterised via the control panel.
(ðSection8.10.3,Page120)
