8 Commissioning/Shutdown
126 of 212
PumpDrive 2
Table101: Parameters for analog output
Parameter Description Possible settings Factory setting
3-8-8-1 Assignment 1 Analog Output 2
Selectable assignment 1 of analog output 2
▪ OFF
▪ Setpoint
▪ Actual Value
▪ Motor Speed
▪ Motor Power
▪ Motor Current
▪ Motor Voltage
▪ Output Frequency
▪ DC Link Voltage
OFF
3-8-8-2 Assignment 2 Analog Output 2
Selectable assignment 2 of analog output 2
OFF
3-8-8-3 Assignment 3 Analog Output 2
Selectable assignment 3 of analog output 2
OFF
3-8-8-4 Assignment 4 Analog Output 2
Selectable assignment 4 of analog output 2
OFF
Digital outputs on the I/O extension board
There are two programmable digital outputs on the I/O extension board.
Table102: Digital output parameters
Parameter Description Possible settings Factory setting
3-8-17-1 Digital Output 1 Function
Selectable messages via digital output 1 of
the I/O extension board
▪ None
▪ AUTO operating mode
▪ RUN operating status
▪ AUTO/SLEEP operating
status
▪ Warning
▪ Alert
▪ Alert or Warning
▪ No alert
▪ Dynamic overload
protection
▪ Current too high
Current too low
▪ Frequency too high
▪ Frequency too low
▪ Power too high
▪ Power too low
▪ Actual value = setpoint
OFF
3-8-17-2 Time Delay ON
Period of time during which the event
selected must be continually available until
the digital output is set
0,0…600,0 s 0,5 s
3-8-17-3 Time Delay OFF
Period of time for which the event selected
must have gone before the digital output is
reset
0,0…600,0 s 0,5 s
