KSB PumpDrive 2 - Page 136

10 Parameter List
136 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
1-2-1-9 Heat Sink Temperature Current temperature of frequency inverter
heat sink
Dependent on the
unit set
1-2-1-10 PCB Temperature Current temperature on the I/O board Dependent on the
unit set
1-2-1-11 Motor Torque Current motor torque based on the motor
speed and mechanical power of the motor
Nm
1-2-2 Pump
1-2-2-1 Pump Suction Pressure Current pressure on the centrifugal pump's
suction side
bar
1-2-2-2 Pump Discharge Pressure Current pressure on the centrifugal pump's
discharge side
bar
1-2-2-3 Pump Differential
Pressure
Difference between the suction- and
discharge-side pump pressure
bar
1-2-2-4 Pump Flow Rate Current flow rate of the pump m3/h
1-2-3 System
1-2-3-1 Actual Value (Closed-
Loop Control)
Current actual value in closed-loop control
mode
%
1-2-3-2 Suction Pressure Current pressure on the suction side of the
system
bar
1-2-3-3 Discharge Pressure Current pressure on the discharge side of
the system
bar
1-2-3-4 Differential Pressure Difference between the suction- and
discharge-side pressure of the system
bar
1-2-3-5 Flow Rate Current flow rate of the system m3/h
1-2-3-6 Level Current fill level m3/h
1-2-3-7 Temperature Current temperature at the measuring
point
°C
1-2-3-8 Flow Velocity Current flow velocity of the fluid in the
system
m/s
1-2-3-9 Head Estimated head at current speed (derived
from N_est. N)
m
1-2-4 Inputs/Outputs
1-2-4-1 Analog Input 1 Value Current signal value present at analog input
1 of the control PCB
mA or V
1-2-4-2 Analog Input 2 Value Current signal value present at analog input
2 of the control PCB
mA or V
1-2-3-4 Analog Input 3 Value
