10 Parameter List
144 of 212
PumpDrive 2
Parameter Description Help text Possible settings Unit Factory setting
3-3-8-2 Integral
Constant_Current (KiI)
Setting the integral constant of the
MotionControl power controller
0 … 9999 Dependent on
size
3-3-8-3 Proportional
Constant_Flux (Kpflx)
Setting the proportional constant of the
MotionControl flux controller
0 … 9999 Dependent on
size
3-3-8-4 Integral Constant_Flux
(Kiflx)
Setting the integral constant of the
MotionControl flux controller
0 … 9999 Dependent on
size
3-3-8-5 Proportional
Constant_Speed (Kpw)
Setting the proportional constant of the
MotionControl speed controller
0 … 9999 Dependent on
size
3-3-8-6 Integral Constant_Speed
(Kiw)
Setting the integral constant of the
MotionControl speed controller
0 … 9999 Dependent on
size
3-3-8-7 Differential
Constant_Speed (Kdw)
Setting the differential constant of the
MotionControl speed controller
0 … 9999 Dependent on
size
3-4 Pump
3-4-1 Pump Nominal Speed Nominal speed of centrifugal pump 0 … 4200 rpm Pump-specific
3-4-2 Number of Pump Stages Number of pump stages. Only relevant for
multi-stage pumps (with respect to power
curve)
1 … 99 Pump-specific
3-4-3 Pump Characteristic
Curve
3-4-3-1 Flow Rate Q_0 Data point 0 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-2 Flow Rate Q_1 Data point 1 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-3 Flow Rate Q_2 Data point 2 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-4 Flow Rate Q_3 Data point 3 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-5 Flow Rate Q_4 Data point 4 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-6 Flow Rate Q_5 Data point 5 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-7 Flow Rate Q_6 Data point 6 for flow rate at nominal speed Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-8 Flow Rate Q_opt Flow rate at the pump's best efficiency
point (BEP)
Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
3-4-3-9 Pump Input Power P_0 Data point 0 for hydraulic performance at
nominal speed
Minimum to maximum limit of value range
set
Dependent on the
unit set
Pump-specific
